Pick your SentryWire System

The SentryWire Series 10/100/200/300/400 Systems are complete systems that come with everything you need. If you want to expand your system at a later date, don't worry you can add throughput, capacity and federate to hundreds of clusters. SentryWire has almost limitless configuration and integration flexibility. You can sort the SentryWire Systems by lossless capture rates.
SentryWire Packet Capture Tool


SentryWire - 10 Series


One (1) 4.4" x 4.56" x 2.04" small form factor Capture Storage Node capturing losslessly from 1 to 100 Megabits per second, with built-in storage capacity and a single RJ45 copper network connection. Assuming 40% bandwidth utilization, a 100Mbps network and 3x compression, this system may store 3.9TB's or 10 days of traffic. All systems can be federated and managed from a single GUI. Other storage options are available.

Sentry 50 White 1 141 33 2.png

One (1) 1U Capture Storage Node capturing losslessly at up to 100 Megabits per second, with built-in storage capacity and 2 network connections. Assuming 40% bandwidth utilization, a 100Mbps network and 3x compression, this system may store 54TB's or 125 days of traffic. All systems can be federated and managed from a single GUI. Other storage options are available.


Expand Your System


SentryWire - 100 Series


One (1) 2U Capture Storage Node capturing losslessly at up to 250 Megabits per second, with built in storage capacity and 2 network connections. Assuming 40% bandwidth utilization, a 250Mbps network and 3x compression, this system may store 216TB's or 200 days of traffic. All systems can be federated and managed from a single GUI. Other storage options are available.


One (1) 2U Capture Storage Node capturing losslessly at up to 500 Megabits per second, with built in storage capacity and 2 network connections. Assuming 40% bandwidth utilization, a 500Mbps network and 3x compression, this system may store 552TB's or 255 days of traffic. All systems can be federated and managed from a single GUI. Other storage options are available.


One (1) 2U Capture Storage Node capturing losslessly at up to 1 Gigabit per second, with built in storage capacity and 2 network connections. Assuming 40% bandwidth utilization, a 1Gbps network and 3x compression, this system may store 665TB's or 125 days of traffic. All systems can be federated and managed from a single GUI. Other storage options are available.


Sentry 150 ES 1 141 26 1.png

One (1) 4U Capture Storage Node capturing losslessly at up to 1 Gigabit per second, with built in storage capacity and 2 network connections. Assuming 40% bandwidth utilization, a 1Gbps network and 3x compression, this system may store 1.06PB's or 195 days of traffic. All systems can be federated and managed from a single GUI. Other storage options are available.


Sentry 180 1 141 33 1.png

One (1) 4U Capture Storage Node capturing losslessly at up to 2 Gigabits per second, with built in storage capacity and 2 network connections. Assuming 40% bandwidth utilization, 2Gbps network and 3x compression, this system may store 1.06PB's or 100 days of traffic. All systems can be federated and managed from a single GUI. Other storage options are available.


Expand your System


SentryWire - 200 Series


Sentry 200 Quad-Lite White 1 141 63 1.png

One (1) 2U Capture Storage Node, capturing at up to 4 Gigabits per second, with built in storage capacity and 4 network connections.

The Sentry200 Quad-Lite contains a minimum of 221TB's of packet storage and with the Sentry200 Quad-Lite in-line compression/compaction could achieve up to 665TB's or more of packet storage. Assuming 40% bandwidth utilization, 4Gbps network and 3x compression, this system may store 40 days of traffic. All systems can be federated and managed from a single GUI. Other storage options are available.


Sentry 200 Quad White 1 141 63 1.png

One (1) 4U Capture Storage Node, capturing at up to 4 Gigabits per second, with built in storage capacity and 4 network connections.

The Sentry200 Quad contains a minimum of 352TB's of packet storage and with the Sentry200 Quad in-line compression/compaction could achieve up to 1.06PB's or more of packet storage. Assuming 40% bandwidth utilization, 4Gbps network and 3x compression, this system may store 60 days of traffic. All systems can be federated and managed from a single GUI. Other storage options are available.


One (1) 4U Capture Storage Node, capturing at up to 5 Gigabits per second, with built in storage capacity and 2 network connections.

The Sentry200 contains a minimum of 352TB's of packet storage and with the Sentry200 in-line compression/compaction could achieve up to 1.06PB's or more of packet storage. Assuming 40% bandwidth utilization, 5Gbps network and 3x compression, this system may store 48 days of traffic. All systems can be federated and managed from a single GUI.  Other storage options are available.


Sentry 215 White 1 141 33 1.png

One (1) 4U Capture Storage Node, capturing at up to 10 Gigabits per second, with built in storage capacity and 2 network connections.

The Sentry215 contains a minimum of 352TB's of packet storage and with the Sentry215 in-line compression/compaction could achieve up to 1.06PB's or more of packet storage. Assuming 40% bandwidth utilization, 10Gbps network and 3x compression, this system may store 25 days of traffic. All systems can be federated and managed from a single GUI. Other storage options are available.


One (1) 4U Capture Storage Node, and One (1) 2U Cluster Node capturing at up to 10 Gigabits per second and 2 network connections.

The Sentry230 contains a minimum of 573TB's of packet storage and with the Sentry230 in-line compression/compaction could achieve up to 1.7PB's or more of packet storage. Assuming 40% bandwidth utilization, 10Gbps network and 3x compression, this system may store 40 days of traffic. All systems can be federated and managed from a single GUI. Other storage options are available.


One (1) 4U Capture Storage Node, and Four (4) 2U Cluster Nodes capturing at up to 20 Gigabits per second and 2 network connections.

The Sentry250 contains a minimum of 1.23PB's of packet storage and with the Sentry250 in-line compression/compaction could achieve up to 3.7PB's or more of packet storage. Assuming 40% bandwidth utilization, 20Gbps network and 3x compression, this system may store 42 days of traffic. All systems can be federated and managed from a single GUI. Other storage options are available.


Expand Your System


SentryWire - 300 Series


Two (2) 4U Capture Storage Node, and Eight (8) 2U Cluster Nodes capturing at up to 40 Gigabits per second and 2 network connections.

The Sentry300 contains a minimum of 2.47PB's of packet storage and with the Sentry300 in-line compression/compaction could achieve up to 7.4PB's or more of packet storage. Assuming 40% bandwidth utilization, 40Gbps network and 3x compression, this system may store 42 days of traffic. All systems can be federated and managed from a single GUI. Other storage options are available.


Three (3) 4U Capture Storage Node, and Twelve (12) 2U Cluster Nodes capturing at up to 60 Gigabits per second and 2 network connections.

The Sentry330 v3 contains a minimum of 3.7PB's of packet storage and with the Sentry330 in-line compression/compaction could achieve up to 11.1PB's or more of packet storage. Assuming 40% bandwidth utilization, 60Gbps network and 3x compression, this system may store 42 days of traffic. All systems can be federated and managed from a single GUI. Other storage options are available.


Four (4) 4U Capture Storage Node, and Sixteen (16) 2U Cluster Nodes capturing at up to 80 Gigabits per second and 2 network connections.

The Sentry350 contains a minimum of 4.94PB's of packet storage and with the Sentry350 in-line compression/compaction could achieve up to 14.8PB's or more of packet storage. Assuming 40% bandwidth utilization, 80Gbps network and 3x compression, this system may store 42 days of traffic. All systems can be federated and managed from a single GUI. Other storage options are available.


Expand Your System


SentryWire - 400 Series


Sentry 400 White 1 141 33 1.png

Five (5) 4U Capture Storage Nodes, capturing at up to 100 Gigabits per second and Twenty (20) 2U Cluster Nodes and 2 network connections.

The Sentry400 contains a minimum of 6.18PB's of packet storage and with the Sentry400 in-line compression/compaction could achieve up to 18.54PB's or more of packet storage. Assuming 40% bandwidth utilization, 100Gbps network and 3x compression, this system may store 45 days of traffic. All systems can be federated and managed from a single GUI. Other storage options are available.


Expand Your System

End Forklift Upgrades & Re-Buys

Imagine buying an IT solution once and upgrading it as needed, without losing a penny on your investment. Start small, SentryWire can grow with your enterprise. As your network throughput increases, simply add another capture node. If you want to increase the amount of network traffic you retain simply add a storage node. You get uninterrupted value from your investment without ever re-buying storage or compute that you already own. Simply add capacity and throughput.


Fork 230.png



Expand Your System
Add Storage, Throughput or Both



Sentry 2U Capture Node White 1 282 29 1.png

The Sentry 2U Capture Node is a complete solution based on a unique capture and storage architecture. The System is managed by a 2U rack-mount system which offers high-speed packet recording with real-time analytics and visualization. Data is then distributed to a cluster of rack-mount nodes with massive high-speed storage.


Sentry 4U Capture Node White 1 282 29 1.png

The Sentry 4U Capture Node is a complete solution based on a unique capture and storage architecture. The system is managed by a 4U rack-mount system which offers high-speed packet recording with real-time analytics and visualization up to 100's of Gbps in a Federated environment. Data is then distributed to a cluster of rack-mount nodes with massive high-speed storage.


Sentry Cluster Node White 1 282 35 1.png

The Sentry Cluster Node is a high-density rack-mount system with massive high-speed storage. It is the foundation for the SentryWire Packet Capture Platform, designed for applications that demand high-speed data recording and extensive storage, such as cyber forensics, cyber security and big data analytics.



Sentry Storage Node White 1 282 34 1.png

The Sentry Storage Node is a high-density 2U rack-mount system for extending the storage of your SentryWire cluster nodes. With 80TBs of additional physical storage per node and compression/compaction resulting in up to 1.6PBs of effective packet storage capacity. The Storage Node scales your system to meet any capacity/timeline needs.



Sentry Series capacities and estimated timelines for the configurations specified above will vary with the network utilization rate, the amount of encrypted traffic and the compression rates achieved with your data.

Portable Systems

The Sentry P1/P2/P3 are portable, brief case size, high-speed packet capture systems that offer indicators of compromise event alerting, BPF filter event triggering and a fully integrated analytics workflow with a collection of open source packet analysis software tools. View IoC logging over a long PCAP forensic timeline and post-process PCAPs for packet analysis and visualization. The Sentry P1/P2/P3 are ideal for network performance monitoring, cyber forensics, compliance enforcement, lawful intercept and packet data analytics.



Sentry P1 1 141 33 1.png

Up to 1Gbps

Sentry P2 1 141 33 1.png

Up to 3Gbps

Sentry P3 1 141 33 1.png

Up to 10Gbps
